Thermodynamic System

A thermodynamic system is a portion of the material space, separated from the rest of the thermodynamic universe (that is, from the external environment) by means of a real or imaginary control surface (or edge), rigid or deformable.

A thermodynamic system can be the seat of internal transformations and exchanges of matter and / or energy with the external environment (that is, everything external to the system that interacts with it).

Classification of thermodynamic systems

Within thermodynamics there are three main types of thermodynamic systems: open, closed and isolated. In particular:

  • Open thermodynamic system. It is said that a system is open if it allows a flow with the external environment, both mass and energy (through heat and / or work and / or other forms of energy), through its limit; An example of an open system is a pond full of water, in which water can enter or leave the pool and can be heated by a wind-cooling and heating system.
  • Closed thermodynamic system. In thermodynamics it is said closed if it allows a flow of energy with the external environment, across its border, (by means of heat and / or work and / or other form of energy), but not of mass; An example is a cylinder kept closed by a valve, which can heat or cool, but does not lose mass (while the same cylinder behaves like an open system if we open the valve).
  • Adiabatic system. A system is adiabatic when it does not exchange heat with the environment.
  • Thermodynamic system isolated. It is said that a system is isolated if it does not allow a flow of energy or mass with the external environment.

Each of these systems can still be schematized due to its internal complexity. The possibility of subdividing into smaller subsystems. In this way we will obtain that an open, adiabatic open, closed, adiabatic and isolated system can be:

  • Simple thermodynamic system: a system is simple if it is limited by a limit, within which there are no other walls.
  • Composite thermodynamic system: a system is composed if it is delimited by a limit, within which there are other walls.

Microscopic and macroscopic description of the thermodynamic system

A thermodynamic system can be seen from a macroscopic and microscopic point of view.

Characteristics of a macroscopic description of a simple system:

  • No assumptions are made about the structure of the system.
  • The quantities necessary to describe it are small quantities: pressure, volume, temperature, amount of gas.
  • They are perceptible by our senses.
  • There is the equation of state of the ideal gas, which is particularly simple and versatile; In addition, other transformation equations facilitate the calculation of the energies and mass exchanged.

Characteristics of a description of an ecosystem

It is a more complicated description, treated at a macroscopic level; but normally the transformations are not ideal and the approach requires a broader basic preparation.

  • We have to make numerous assumptions about the structure of the system, which is made up of different substances in different phases.
  • The quantities are in large quantities.
  • Sometimes the causes and effects of friction escape perception.
  • They consist of many interacting elements, sometimes in a complex way.
  • Sometimes the mathematical competence of dealing with very large numbers is required.

Characteristics of the molecular description of a system

  • It is a more complicated description, the approach requires a broader basic preparation, generally requires bases of statistical thermodynamics.
  • It is necessary to make numerous assumptions about the structure of the system, which consists of different substances in different phases.
  • The quantities are in large quantities.
  • Sometimes the causes and effects of friction escape perception.
  • They are composed of many elements that interact independently.
  • Sometimes, mathematical competence is necessary to handle very large numbers or rather abstract concepts.

Sometimes this level is called microscopic, but atoms the molecules are not visible under the microscope; In addition, Heisenberg's uncertainty principle is almost always important at the molecular level.

Simple system: To describe an ideal gas in the cylinder macroscopically, it is sufficient to take into account pressure, temperature, quantity of gas and volume.

Molecular system: To describe a molecular system it is necessary to consider the molecules and atoms and describe mathematically all the positions they assume as the pressure, volume and temperature change, taking into account the uncertainty principle, which causes the behavior of the system and its elementary components.

Control surface

The control surface (more commonly called the boundary, or the wall), is that entity, materially or purely geometric, that separates the system from the external environment; An example of a material wall is the surface of a cylinder (usually cast iron), while an example of a geometric wall is the contact surface between air and water in a glass (or even between water and glass).

Classification of a control area

The wall of a thermodynamic system can be classified by three essential parameters: permeability, rigidity and thermal.

Depending on its impermeability, the wall can be impermeable that does not allow a flow of matter) or porous that allows a flow of matter, even selectively (as the name implies).

Depending on the stiffness the wall can be rigid (it does not allow changes in volume, therefore it works) or mobile (it allows variations in volume, so work)

Depending on the thermal the wall can be adiabatic wall (does not allow heat exchange) or diathermic wall (allows heat exchange).

Classification according to its thermodynamic systems. The aforementioned thermodynamic systems are nothing more than a combination of these properties:

  • Open system: porous, mobile and diathermic wall
  • Open adiabatic system: porous, mobile and adiabatic wall
  • Closed system: waterproof, mobile and diathermic wall
  • Closed adiabatic system: waterproof, mobile and adiabatic wall
  • Insulated system: waterproof, rigid and adiabatic wall.
